China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 45t electric reach stacker | srsc45e2a (range-extended) in China. With abundant experience, we warmly welcome you to buy cheap 45t electric reach stacker | srsc45e2a (range-extended) made in China here from our factory. For price consultation, contact us.
Efficient Range Extender
■ Specialized engine with 4.03 kWh/L fuel efficiency
Extended Range, Lower Fuel Use
■ 75kW power supports heavy-duty work
■ Fuel use only 13L/h, 20% less than traditional models
Product Parameters
 |  |  |  |
Technical Parameter | ||
ITEM | UNIT | SRSC45E2A (Range-Extended) |
Max. Lifting Speed (0/full load) | mm/s | 420/250 |
Max. Lowering Speed (0/full load) | mm/s | 360/300 |
Max. Traveling Speed (0/full load) | km/h | 20/14 |
Gradeability (0/full load) | % | 21/14 |
Hydraulic System Working Pressure | bar | 350 |
Overall Weight | t | 71 |
Rated Load | t | 45 |
Stack Layer | - | 5 |
Max. Lift Height Standard | mm | 15100 |
Max. Boom Elevation | deg | 0-60 |
Overall Length (L) | mm | 11320 |
Wheel Base (L1) | mm | 6000 |
Overall Height (H)-retract/extend) | mm | 4850 |
Min. Ground Clearance (H1) | mm | 270-330 |
Overall Width (W) | mm | 6053-12185 |
Front Gauge (T1) | mm | 3033 |
Rear Gauge (T2) | mm | 2790 |
Min. Turning Radius (R) | mm | 8000 |
Aisle Width For 20/container (A1) | mm | 11300 |
Aisle Width For 40/container (A2) | mm | 13600 |
Configuration Parameter | ||||
CONFIGURATION | UNIT | SRSC45E2A | ||
Energy Type | - | Range-Extended | ||
Battery Capacity (kWh) | kWh | 282 | ||
Power Battery | Battery Type | - | LFP | |
Nominal Voltage | V | 618 | ||
Thermal Management | - | Heating:Heating Film | ||
Electric Motor | Type | - | PMSM | |
Output Torque (Rated/peak) | Nm/rpm | 2040(Rated) 3860(peak) | ||
Output power (Rated/peak) | kW | 171(Rated) 310(peak) | ||
Output rotate speed (Rated/peak) | RPM | 800(Rated) 2800(peak) | ||
Cooling Type | - | Water Cooling | ||
Transmission Type | - | Sany Dwf-50/101.287 | ||
Range Extender | Fsg Motor Power | kW | 75 | |
Cooling Method | - | Water Cooling | ||
Engine Power | kW | 92 | ||
Emission Standard | - | Nationlly | ||
