- Front Gauge (T1):3033mm
- Rear Gauge (T2):2790mm
- Min. Turning Radius (R):8000mm
- Max. Traveling Speed (0/full load):25/21km/h
- Gradeability (0/full load):39/32%
- Hydraulic System Working Pressure:260bar
- Max. Traveling Speed (0/Full load):25 / 21km/h
- Gradeability (0/Full load):46 / 28%
- Hydraulic System Working Pressure:260bar
- Overall Height(H) (retract/extend):4770mm
- Min. Ground Clearance (H1):350mm
- Overall Width (W):6055-12185mm
- Max Lifting Speed (unloaded-loaded):420/250mm/s
- Max Lowering Speed (unloaded-loaded):350/300mm/s
- Climbing Ability (unloaded-loaded):21/14
- Rear Gauge (T2):2790mm
- Min. Turning Radius (R):8000mm
- Aisle Width For 20'container (A1):11300mm
