China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 600kg hydrostatic loader | jh7706 in China. With abundant experience, we warmly welcome you to buy cheap 600kg hydrostatic loader | jh7706 made in China here from our factory. For price consultation, contact us.
The advantage of Hydrostatic Wheel Loader
Transmission System:
Employs a variable displacement piston pump + hydraulic motor (closed-loop), featuring an advanced transmission system.
Speed Control:
Steplessly adjustable speed with smooth shifting.
Operational Performance:
Fast response and precise control.
Fuel Efficiency:
Higher efficiency, saving 10-20% on fuel.
Operating Comfort:
Extremely smooth operation.
Suitable Scenarios:
Suitable for medium-sized loaders in situations requiring frequent forward/reverse operations.
 |  |
Main specification
Item / Model | 7706 | 7708 |
Overall Length (A): mm | 4295 | 4235 |
Wheelbase (B): mm | 1400 | 1560 |
Ground Clearance (C): mm | 270 | 400 |
Digging Depth (D): mm | 155 | |
Total Wheel Width (E): mm | 1146 | 1310 |
Wheel Center Distance (F): mm | 865 | 930 |
Max Boom Lifting Height (G): mm | 2785 | 2958 |
Discharging Distance (H): mm | 757 | 605 |
Overall Height (Min Transport Height, I): mm | 2203 | 2470 |
Bucket Rollback Angle (J) | 55 | 55 |
Dumping Angle (K) | 35 | 35 |
Overall Length (Without Bucket, L) | 3535 | 3475 |
Overall Length (With Bucket, M) | 4445 | 4385 |
Dumping Height (N): mm | 1982 | 2155 |
Loading Height (O): mm | 2478 | 2650 |
Engine | Kubota D1105 | Kubota D1105 |
Weight: T | 2 | 2.3 |
Turning Radius: mm | Mini 1641,Max 3438 | Mini 1749,Max 3344 |
Steering Angle | 35 | 35 |
Tire Width: mm | 260 | 380 |
Tire Model | 26*12.00-12 | 31-15.5-15-3 |
Bucket Capacity: m³ | 0.25 | 0.25 |
Fuel Tank Capacity: L | 30 | 30 |
Working System Pressure: Mpa | 16 | 16 |
Travel Speed: KM/h | 14 | 14 |
Max Lifting Time: s | 5 | 5 |
Up/Down Swing Angle (Single Side): ° | 6° | 6° |
Normal Lifting Weight: KG | 600 | 800 |
Max Steering Angle Lifting Weight: KG | 400 | 530 |
Minimum Ground Clearance: mm | 170 | 245 |
