Product Description
The LTD216H 16t Hydraulic Drive Single Drum Road Roller is a heavy-duty compaction machine built with international advanced technology and high-quality imported components. Powered by a CUMMINS 6BT5.9 turbocharged engine (110 kW) and weighing 16,000 kg, it delivers high centrifugal force and uniform compaction on a variety of surfaces. Designed for gravel, macadam, asphalt, sand, and cohesive soils, the LTD216H is ideal for highways, mining roads, embankments, ports, and large-scale industrial construction projects.
 |  |
Main Features
Powerful Engine & Hydraulic System –
CUMMINS turbocharged diesel with full hydraulic double-drive and articulated steering ensures smooth, safe, and precise operation.
High-Efficiency Compaction –
Centrifugal force 290/180 kN, vibration amplitude 2.0/1.0 mm, vibration frequency 28/35 Hz, travel speed up to 12 km/h.
Flexible Drum Options –
Standard padfoot or removable padfoot for different soil and asphalt applications.
Ergonomic & Durable Design –
Streamlined hood, circular windshield, reinforced frame, and DANFOSS 90-series hydraulic & vibration system for long-term reliability and operator comfort.
 |  |
Model | LTD216H |
Operating mass | 16000kg |
Static linear load | 428N/cm |
Vibration amplitude | 2.0/1.0mm |
Centrifugal force | 290/180Kn |
Vibration frequency | 28/35Hz |
Travel speed | 0-12Km/h |
Ground clearance | 432mm |
Electrical voltage | 24V |
Tire size | 23.1-26 |
Grade ability | 35% |
Turning radius | 7000mm |
Overall dimension (LxWxH) | 6025x2280x3050mm |
Drum rim thickness | 24mm |
Drum width | 2100mm |
Wheel base | 3265mm |
Diesel engine power | 110/2200rpm |
Diesel engine model | CUMMINS 6BT5.9 |
Fuel tank capacity | 220L |
Hydraulic tank capacity | 160L |
Driving system | DANFOSS |
Vibration system | DANFOSS |
Ship | 1 unit/40HQ |
Optional:removable padfoot,Top-mounted air conditioner | |
