China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 45t electric reach stacker | c45e6 (charge) in China. With abundant experience, we warmly welcome you to buy cheap 45t electric reach stacker | c45e6 (charge) made in China here from our factory. For price consultation, contact us.
Lower Energy Use
■ Low-pressure-loss hydraulics cut losses by 60%
■ Energy recovery lowers total consumption by 30%
Enhanced Structural Stability
■ U-type boom improves durability
■ Counterweight moved back 1m for better balance
■ 67T weight reduces driving energy use by 16%
Improved Visibility
■ Dual full-coverage wipers improve visibility by 15%
Smart and Comfortable Cabin
■ Multifunction joystick and suspension seat
■ Dual-mode AC
■ Laminated curved glass keeps noise <70dB
Product Parameters
 |  |  |  |
Technical Parameter | ||
ITEM | UNIT | SRSC45E5 |
Weight | t | 67 |
Dimensions (L × W × H) | mm | 11288×6053×4965 |
Rated Lifting Capacity | t | 45 |
Max Lifting Height / Stacking Layers | mm | 15100/5th floor |
Max Boom Angle | deg | 60 |
Max Lifting Speed (unloaded-loaded) | mm/s | 420/250 |
Max Lowering Speed (unloaded-loaded) | mm/s | 350/300 |
Climbing Ability (unloaded-loaded) | - | 21/14 |
Hydraulic System Operating Pressure | bar | 380 |
Max Travel Speed | km/h | 20 |
Minimum Ground Clearance | mm | 300–330 |
Counterweight Reversal Angle | deg | 42 |
Minimum Turning Radius | mm | 8000 |
20' Container Passage Width (A1) | mm | 11300 |
40' Container Passage Width (A2) | mm | 13600 |
Configuration Parameter | ||||
CONFIGURATION | UNIT | SRSC45E5 | ||
Energy Type | - | Electric | ||
Charging Time(20%~80%) | min | 75 (507kWh) | ||
Endurance Time | 9~10 (507kWh) | |||
Battery Capacity (Kwh) | kWh | 422/507 | ||
Battery Type | - | LFP | ||
Power Battery | Nominal Voltage | V | 618 | |
Thermal Management | - | Heating:Heating棒 | ||
Electric Motor | Type | - | PM/SIM | |
Output Torque (Rated/peak) | Nm/rpm | 1500(Rated) 4200(peak) | ||
Output Power (Rated/peak) | kW | 157(Rated) 310(peak) | ||
Output Rotate Speed (Rated/peak) | RPM | 1000(Rated) 2800(peak) | ||
Cooling Type | - | Water Cooling | ||
