China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 8t wheel excavator | jh9080 in China. With abundant experience, we warmly welcome you to buy cheap 8t wheel excavator | jh9080 made in China here from our factory. For price consultation, contact us.
Key Features
Upgraded YC4FA65 Engine –
48kW @ 2200rpm, Tier III, improved power & efficiency
Hydraulic Pilot Servo System –
Smooth, precise control
Enhanced Stability –
Wet axle + reinforced chassis design
Luxury Cabin –
Fully sealed with A/C, LCD display & LED lighting
Breaker Pipeline Ready –
Quick attachment adaptability
Optimized Mobility –
8.25-16 tires for versatile terrain performance
0.28m³ Bucket Capacity –
Balanced digging efficiency
 |  |
Main Applications
Urban & municipal construction
Road maintenance & repair
Landscaping & utility works
Light excavation & trenching
Material handling & site transfer
 |  |
Parameters
| Model | JH9080 | |
ENGINE | Emission Standard | Tier 3/ Stage III |
Make /Model | Yuchai / YC4FA65 | |
Power /Rotation speed | 48kw//2200rpm | |
Type | Diesel with water-cooled, | |
PERFORMANCE PARAMETER | Standard Bucket capacity | 0.28m³ |
Swing speed | 11rpm | |
Maximum Grade ability | 30° | |
Travel speed | 28km/h | |
Maximum Bucket digging force | 45KN | |
Maximum Arm digging force | 36KN | |
Hydraulic system pressure | 28Mpa | |
Machine weight | 8000kg | |
Fuel tank | 200L | |
Hydraulic oil tank | 90L | |
Main Dimensions
MACHINE SIZE | Overall dimension (L*W*Hmm) | 6620*2172*2773mm |
Tread width | 8.25-16 | |
Width of chassis | 2108mm | |
Length to center of rollers | 2400mm | |
Wheel(track)Distance | 1668mm | |
Minimum Ground clearance | 239mm | |
Swing radius at tail | 1787mm | |
WORKING RANGE | Maximum Digging height | 7274mm |
Maximum Dumping height | 5450mm | |
Maximum Digging depth | 3645mm | |
Maximum Vertical digging depth | 2606mm | |
Maximum Digging radius | 6486mm | |
Minimum swing radius | 2045mm | |
Length of boom | 3725mm | |
Length of arm | 1620mm |
