China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 3t wheel loader | 636 in China. With abundant experience, we warmly welcome you to buy cheap 3t wheel loader | 636 made in China here from our factory. For price consultation, contact us.
Product Features
Powerful & Reliable Engine:
Weichai high-pressure diesel engine with low-noise design, ideal for urban construction. Delivers strong power and stable performance under heavy loads.
Heavy-Duty Transmission:
Hydraulic shift fixed-axis gearbox with reinforced axle for excellent load capacity, suitable for mines and high-intensity infrastructure work.
Robust Frame Structure:
Long wheelbase center layout with robot welding technology ensures balanced axle load, superior torsion resistance, and stable operation on rough terrain.
Efficient Hydraulic System:
Single-pump flow-dividing technology enables faster boom lifting, greater digging force, and light, flexible steering for improved efficiency and energy savings.
Comfortable Cab:
Luxury cabin with panoramic visibility to reduce blind spots. Ergonomic, multi-directional adjustable suspension seat enhances safety and comfort.
Easy Maintenance:
Three-section independent hood design (front, middle, rear) provides convenient access to all service points, reducing maintenance time.
Durable Bucket & Attachments:
Wear-resistant bucket plate, teeth, and cutting edge made of high-strength materials. Optional attachments include rock bucket, enlarged bucket, high dump arm, side dump bucket, log fork, grass grab, and more to suit various applications.
 |  |
Parameters
| Model | 636 |
Bucket capacity | 1.7m3 |
Rated load | 3.0t |
Operating weight | 10.0t |
Climbing gradient | ≥26° |
Breakout force | ≥95kN |
Tranction force | ≥97kN |
Total time | 9.4s |
Engine | |
Type | WP6G125E22 |
Rated power | 92kW |
Rated speed | 2200r/min |
Max. torque | 500Nm |
Total air displacement | 6.75L |
Rated fuel consumption rate ≤220g/(kWh) | |
Transmission system | |
Hydraulic torque conterver | |
Type | YJ315S-3S |
Torque vcoefficient | 3.2 |
Gearbox | |
Type | LGX833VA.03A |
Transmission pressure | 1.1-1.5MPa |
Driving axle | |
Reduction ratio | 20.26 |
Tyre | |
Specification | 17.5-25 |
Tyre pressure | 0.30MPa |
Travel speed | |
Forward gear Ⅰ | 7.0km/h |
Forward gear Ⅱ | 12.0km/h |
Forward gear Ⅲ | 24.0km/h |
Forward gear Ⅳ | 36.0km/h |
Reverse gear Ⅰ | 8.5km/h |
Reverse gear Ⅱ | 28.0km/h |
Steering system | |
Steering pump displacement | 112 ml/r |
Working pressure | 15MPa |
Number of steering cylinder-bore×stoke | 2-φ80×315 |
Working hydraulic system | |
Number of lift cylinder-bore×stoke | 2-φ125×784 |
Number of tilt cylinder-bore×stoke | 1-φ140×553 |
Displacement of working pump | 112 ml/r |
Working pressure | 16MPa |
Distribution valve | HDF25 |
Brake system | |
Driving brake(Foot-brake) | |
Air-pushing-oil disc brake on four wheels | |
Parking brake(Hand-brake) | |
Cable-controlled callper disc brake | |
▲ Note: The content and performance will be revised and the products will be improved without notice . Please confirm the data and performance with real products. We deserve the right of property.
