Product Description
Powerful Engine:
Weichai turbocharged diesel engine delivering strong power, fuel efficiency, and high performance.
Heavy-Duty Drivetrain:
Reinforced planetary gearbox and heavy-duty axle ensure high reliability and excellent load capacity.
High-Strength Frame:
Newly designed frame structure using finite element analysis and automated welding for superior strength, load-bearing capacity, and torsion resistance.
Durable Centered Frame:
Large-span center articulation design enhances durability and stability under complex working conditions.
Advanced Hydraulics:
Full hydraulic load-sensing steering with dual-pump confluence system for faster lifting speed, stronger digging force, and smooth, responsive operation.
Upgraded Cabin:
Modern cab with luxury interior, excellent sealing, and panoramic glass for a wider field of view.
Auto Leveling System:
Intelligent automatic leveling simplifies operation, reduces operator fatigue, and improves efficiency.
Reinforced Bucket:
Wear-resistant bucket plate, teeth, and main blade for higher strength and longer service life.
Optional Attachments:
Rock bucket, enlarged bucket, high-dump arm, side-dump bucket, log fork, grass grab, and more to suit different applications.
 |
Parameters
| Model | 656 |
Bucket capacity | 2.7m³ |
Rated load | 5.0t |
Operating weight | 16.6t |
Climbing gradient | ≥28° |
Breakout force | ≥170kN |
Tranction force | ≥155kN |
Total time | 10.0s |
Engine | |
Type | WD10G220E21 |
Rated power | 162kW |
Rated speed | 2200r/min |
Max. torque | 850Nm |
Total air displacement | 9.726L |
Rated fuel consumption rate" ≤215g/(kWh) | |
Transmission system | |
Hydraulic torque conterver | |
Type | YJSW315-6J01-22 |
Torque vcoefficient | 4.4±0.24 |
Gearbox | |
Type | ZL50 |
Transmission pressure | 1.2～1.5MPa |
Driving axle | |
Reduction ratio | 23.276 |
Tyre | |
Specification | 23.5-25 |
Tyre pressure | 0.30MPa |
Electrical system | |
Voltage | 24V |
Battery type | 6-QW-120B |
Travel speed | |
Forward gear Ⅰ | 11.5km/h |
Forward gear Ⅱ | 36km/h |
Reverse gear Ⅰ | 16km/h |
Steering system | |
Steering pump displacement" | 80ml/r |
Working pressure | 16MPa |
Number of steering cylinder-bore×stoke" | 2-φ100×324 |
Working hydraulic system | |
Number of lift cylinder-bore×stoke" | 2-φ160×799 |
Number of tilt cylinder-bore×stoke" | 1-φ200×563 |
Displacement of working pump" | 100ml/r |
Working pressure | 16MPa |
Distribution valve DF32.2C D32-00 | |
Brake system | |
Driving brake(Foot-brake)" | |
Air-pushing-oil disc brake on four wheels" | |
Parking brake(Hand-brake)" | |
Cable-controlled callper disc brake" | |
