China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 240hp bulldozer | hd24 in China. With abundant experience, we warmly welcome you to buy cheap 240hp bulldozer | hd24 made in China here from our factory. For price consultation, contact us.
Key Features
High-Performance Diesel Engine
Equipped with Cummins NT855-C280 engine (187 kW / 254 HP), offering strong torque, excellent fuel efficiency, and reliable operation. Paired with a power shift transmission and two-stage final drive, it delivers smooth, efficient performance for demanding tasks.
Smart Control & Operator Comfort
Integrated cast instrument panel with air conditioning and automatic fault monitoring enables full machine oversight. Ergonomic adjustable seat and armrest, combined with optimized control layout and servo-assisted operation, make driving light, precise, and fatigue-free.
Durable Frame & Long-Lasting Reliability
Full box-type welded steel main frame, reinforced with rear axle box, provides exceptional resistance to impact, bending, and twisting. High-quality welding ensures the bulldozer can withstand heavy-duty and long-term operations.
Flexible Working Tools
Standard straight tilt blade offers powerful cutting capability, while optional single or three-shank rippers allow efficient ripping of clay and frozen earth, maximizing productivity across various construction scenarios.
 |  |
Main Applications
Earthmoving and bulk material handling
Stone and mining construction projects
Road, railway, and infrastructure works
Land leveling and heavy-duty construction
Main specification
Model | HD24 |
Type | 254HP Hydraulic Standard Type Bulldozer |
| Engine model | CUMMINS NT855-C280 |
Displacement(L) | 14 |
Rated power(kw/rpm) | 187/1850 |
Max.torque(N.m/rpm) | 1131/1200 |
Operating weight | 23.5 Ton |
Dimension(no ripper)(mm) | 5460×3735×3600 |
Grounding length(mm) | 2730 |
Ground pressure(MPa) | 0.077 |
Track gauge(mm) | 2000 |
Dozing capacity(m³) | 6.4 |
Blade width(mm) | 3735 |
Blade height(mm) | 1317 |
Max drop below ground(mm) | 540 |
Track shoe width(mm) | 560 |
Pitch(mm) | 216 |
Quantity of track link | 38 |
Quantity of Carrier rollers(each side) | 2 |
Quantity of Track rollers(each side) | 6 |
Max pressure(MPa) | 14 |
Discharge L/min | 262 |
Max tractor force(KN) | 202 |
Forward Speed(Km/h) | F1:0-3.6 |
F2:0-6.5 | |
F3:0-11.2 | |
Rear Speed(Km/h) | R1:0-4.3 |
R2:0-7.7 | |
R3:0-13.2 |
Notice : Material and specifation are subject to change without notice , Feature machine in photos may include additional equipment
