Hydraulic System for Precise Control

5-section main boom with large U-shaped cross-section (100T class), fully extended length 50.5 m;standard 17.5 m jib, optional 9.5 m extension, maximum lifting height up to 78 m

Electronically controlled dual-swing, three-stage reduction system, combined with a large-displacement hydraulic pump;smooth start/stop without impact, torque increased by 35%, load capacity improved by 10%,minimum stable slewing speed 0.08°/s, ensuring powerful slewing for long-radius operations

H-type low-position outriggers, span 8 × 6.53 m;standard 20.5 t counterweight, optional 2 × 2.5 t side counterweights (80T universal)

Max lifting moment (basic boom): 3469 kN·m (59 t × 6 m)

Max lifting capacity with full boom: 16 t, working radius up to 44 m

Advanced Hydraulic & Control System

New electro-proportional dual-pump intelligent flow distribution system

Independent luffing + combined boom extension, improving compound operation efficiency by over 50%

Variable displacement piston motor winch, noise reduced by 7 dB,minimum stable hoisting speed 0.8 m/min

Innovative automatic lowering compensation technology, ensuring smoother luffing-down operations

Human-Centered Operation System

Brand-new "Lingzhi" dual-cabin design, equipped with upgraded ergonomic seats

(150 mm sliding adjustment, 140° reclining angle)

20% larger upper cabin operating space, with sliding track doors for easy access

Sliding step + foldable front pedal for smooth entry/exit

New interior design with multi-channel 3D airflow system, panoramic sunroof, adjustable seats, and softened trim materials

Equipped with electric wipers and standard winch monitoring system, ensuring more comfortable and easy operation

Powerful Chassis Performance

Equipped with Yuchai K09 high-torque engine + 12-speed synchronizer gearbox

(optional Weichai WP10H engine + 10-speed gearbox)

Heavy-duty axle design, max travel speed 80 km/h, max gradeability 45%

7-inch HD LCD instrument panel in chassis cab, with co-driver seat for improved usability

Second-generation heavy-duty suspension system, allowing transportation with 20.5 t counterweight without unloading for short distances

Tire configuration: Front 4 × 385/95R25 + Rear 8 × 325/95R24,

enabling counterweight transport while leaving space for outrigger pads

450 L large-capacity fuel tank, increasing endurance by 30%
