China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 14trear wheel drive road roller | lts214h in China. With abundant experience, we warmly welcome you to buy cheap 14trear wheel drive road roller | lts214h made in China here from our factory. For price consultation, contact us.
LTS214H Key Highlights
High-Efficiency Compaction –
CUMMINS turbocharged engine and hydraulic vibration for consistent, uniform results.
Smooth & Safe Operation –
Full hydraulic double-drive with articulated steering and ergonomic cabin for operator comfort.
Versatile Drum Options –
Padfoot or removable padfoot drums for a wide range of compaction tasks.
Durable & Reliable –
Reinforced frame and advanced DANFOSS 90-series hydraulic system for long-term heavy-duty performance.
 |  |
Applications
Highways, expressways, and airport pavements
Mining roads and industrial construction sites
Embankments, ports, and large-scale earthworks
Non-cohesive and cohesive soils, including gravel, macadam, sand, and mixed aggregates
 |  |
Model | LTS214H |
Operating mass | 14000kg |
Static linear load | 326N/cm |
Vibration amplitude | 1.7/0.8mm |
Centrifugal force | 290/180Kn |
Vibration frequency | 29/35Hz |
Travel speed | 0-12Km/h |
Ground clearance | 432mm |
Electrical voltage | 24V |
Tire size | 17.5-25 |
Grade ability | 30% |
Turning radius | 7000mm |
Overall dimension (LxWxH) | 5900x2280x3050mm |
Drum rim thickness | 24mm |
Drum width | 2100mm |
Wheel base | 3185mm |
Diesel engine power | 110/2200rpm |
Diesel engine model | CUMMINS 6BT5.9 |
Fuel tank capacity | 220L |
Hydraulic tank capacity | 160L |
Driving system | DANFOSS |
Ship | 1 unit/40HQ |
Optional:removable padfoot | |
