China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 10t all wheel drive road roller | ltd210h in China. With abundant experience, we warmly welcome you to buy cheap 10t all wheel drive road roller | ltd210h made in China here from our factory. For price consultation, contact us.
LTD210H Key Highlights
Powerful Performance –
CUMMINS 6BT5.9 turbocharged engine with 110 kW ensures efficient, high-power compaction.
Hydraulic Double-Drive & Vibration –
smooth, precise operation with articulated steering for safe and reliable handling.
Versatile Drum Options –
padfoot or removable padfoot for different soil and asphalt surfaces.
Durable & Heavy-Duty –
robust frame and advanced DANFOSS hydraulic system for long-term industrial use.
 |  |
Applications
Highways, expressways, and asphalt paving
Mining roads and industrial construction
Embankments, ports, and large-scale infrastructure
Gravel, macadam, sand, and cohesive soils
 |  |
Model | LTD210H |
Operating mass | 10000kg |
Static linear load | 326N/cm |
Vibration amplitude | 1.7/0.8mm |
Centrifugal force | 260/160Kn |
Vibration frequency | 28/35Hz |
Travel speed | 0-12Km/h |
Ground clearance | 360mm |
Electrical voltage | 24V |
Tire size | 17.5-25 |
Grade ability | 35% |
Turning radius | 7000mm |
Overall dimension (LxWxH) | 5650x2280x3000mm |
Drum rim thickness | 24mm |
Drum width | 2100mm |
Wheel base | 3060mm |
Diesel engine power | 110/2300rpm |
Diesel engine model | CUMMINS 6BT5.9 |
Fuel tank capacity | 220L |
Hydraulic tank capacity | 160L |
Driving system | DANFOSS |
Vibration system | DANFOSS |
Ship | 1 unit/40HQ 3units/2x40HQ |
Optional:removable padfoot,Top-mounted air conditioner | |
