China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 12t battery forklift | fb120 in China. With abundant experience, we warmly welcome you to buy cheap 12t battery forklift | fb120 made in China here from our factory. For price consultation, contact us.
Product Introduction
1. Mature & Stable Axle Components
As a heavy-duty industrial handling equipment, it employs mature and stable axles from internal combustion forklifts, including drive axles and steering axles. Their extensive market adoption ensures convenient maintenance and consistent quality, widely recognized and serviced by technicians, minimizing downtime and repair complexities.
2. High-Energy-Density Lithium Batteries
Equipped with high-energy-density lithium batteries, it delivers extended operational endurance. Even under 12-ton heavy-duty conditions, the batteries sustain continuous and efficient performance, reducing frequent charging and downtime to enhance overall productivity, perfectly adapting to intensive work cycles in warehouses and manufacturing facilities.
3. Low-Maintenance & Cost-Saving Design
Unlike traditional lead-acid batteries that require regular water refills and cleaning, the lithium batteries demand minimal maintenance, significantly cutting down upkeep workload and costs. Their prolonged service life reduces battery replacement frequency, optimizing long-term operational expenses and reducing waste.
4. Eco-Friendly & Energy-Efficient Performance
This lithium-powered forklift achieves zero exhaust emissions, boasting the environmental advantage of zero pollution. The lithium batteries feature high charging efficiency with low energy loss during conversion, saving energy consumption, reducing carbon footprints and operational costs, aligning with sustainable industrial practices.
5. Application Scenarios
Ideal for heavy-duty industrial handling scenarios, widely used in large warehouses, manufacturing facilities, logistics hubs and high-load industrial sites. It is specifically designed for 12-ton heavy goods transportation, meeting intensive work demands while balancing environmental protection, efficiency and cost savings.
 |  |  |
 |  |  |  |
Parameters
Model | FB120 | |
Rated Capacity | kg | 12000 |
Load Center Distance | mm | 600 |
Power Type | Lithium Battery | |
Wheel Base | mm | 2800 |
Wheel Number(Front/Rear) | 4×/2 | |
Front Tread | mm | 1600 |
Rear Tread | mm | 1722 |
Tyre(Front) | 9.00-20-16PR | |
Tyre(Rear) | 9.00-20-16PR | |
Front Overhang | mm | 720 |
Mast Tilting Angle,Front/Rear | 6/12 | |
Height With Mast Retraction | mm | 2840 |
Free Lifting Height | mm | 200 |
Max.Lifting Height | mm | 3000 |
Max.Height After Lifting | mm | 4320 |
Overall Guard Height | mm | 2560 |
Fork Size:Length X Width X Thickness | mm | 1220×150×85 |
Overall Length(Fork Excluded) | mm | 4260 |
Overall Width | mm | 2240 |
Turning Radjus | mm | 4080 |
Ground Clearance Of Mast | mm | 235 |
Ground Clearance Of Wheel Base Center(Loaded) | mm | 245 |
Right Angle Stacking Aisle Width (Pallet 1000×1000Mm),Clearance 200Mm | mm | 5750 |
Right Angle Stacking Aisle Width (Pallet 1200×1200Mm),Clearance 200Mm | mm | 5950 |
Lateral Fork Adjustment Max./Min | mm | 2200-300 |
Travelling Speed (Loaded/Unloaded) | km/h | 13/15 |
Lifting Speed (Loaded/Unloaded) | mm/s | 280/300 |
Lowering Speed | mm/s | 450 |
Gradeability (Loaded) | % | 14 |
Self Weight | Kg | 95000 |
Battery Voltage /Capacity | V/Ah | 76.8/1120 |
Battery Weight | Kg | 720 |
Driving Motor Power-60 Minutes | Kw | 30 |
Lifting Motor Power(S315%) | Kw | 2X26 |
Driving Motor Control Mode | MOSFET/AC | |
Lifting Motor Control Mode | MOSFET/AC | |
Service Brake/Parking Brake | Hydraulic /Mechanical | |
Hydraulic System Working Pressure | Mpa | 20.0 |
With technological innovation our product configuration and parameters will continue to change without notice;
If there is any doubt the specific confirmation of our international trade sales shall prevail;
