China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 10t battery forklift | fb100 in China. With abundant experience, we warmly welcome you to buy cheap 10t battery forklift | fb100 made in China here from our factory. For price consultation, contact us.
Product Introduction
Lithium-powered forklifts produce no exhaust emissions, offering superior environmental friendliness. Additionally, lithium batteries boast high charging efficiency and low energy conversion losses, saving energy consumption while helping to reduce carbon footprints and operational costs. This dual advantage aligns with sustainable industrial practices and cost-saving objectives.
It is widely applicable to heavy machinery manufacturing, port container transportation, building materials warehousing, new energy projects (such as wind power equipment handling) and other fields. It is especially suitable for industrial material transportation scenarios with daily operation hours exceeding 6 hours and single handling weight exceeding 5 tons, becoming a green productivity tool to replace fuel-powered heavy forklifts.
 |  |  |
 |  |  |  |
Parameters
Model | FB100 | |
Rated Capacity | kg | 10000 |
Load Center Distance | mm | 600 |
Power Type | Lithium Battery | |
Wheel Base | mm | 2800 |
Wheel Number(Front/Rear) | 4×/2 | |
Front Tread | mm | 1600 |
Rear Tread | mm | 1722 |
Tyre(Front) | 9.00-20-16PR | |
Tyre(Rear) | 9.00-20-16PR | |
Front Overhang | mm | 720 |
Mast Tilting Angle,Front/Rear | 6/12 | |
Height With Mast Retraction | mm | 2840 |
Free Lifting Height | mm | 200 |
Max.Lifting Height | mm | 3000 |
Max.Height After Lifting | mm | 4320 |
Overall Guard Height | mm | 2560 |
Fork Size:Length X Width X Thickness | mm | 1220×150×85 |
Overall Length(Fork Excluded) | mm | 4260 |
Overall Width | mm | 2240 |
Turning Radjus | mm | 4080 |
Ground Clearance Of Mast | mm | 235 |
Ground Clearance Of Wheel Base Center(Loaded) | mm | 245 |
Right Angle Stacking Aisle Width (Pallet 1000×1000Mm),Clearance 200Mm | mm | 5750 |
Right Angle Stacking Aisle Width (Pallet 1200×1200Mm),Clearance 200Mm | mm | 5950 |
Lateral Fork Adjustment Max./Min | mm | 2200-300 |
Travelling Speed (Loaded/Unloaded) | km/h | 13/15 |
Lifting Speed (Loaded/Unloaded) | mm/s | 280/300 |
Lowering Speed | mm/s | 450 |
Gradeability (Loaded) | % | 14 |
Self Weight | Kg | 95000 |
Battery Voltage /Capacity | V/Ah | 76.8/1080 |
Battery Weight | Kg | 720 |
Driving Motor Power-60 Minutes | Kw | 30 |
Lifting Motor Power(S315%) | Kw | 2X26 |
Driving Motor Control Mode | MOSFET/AC | |
Lifting Motor Control Mode | MOSFET/AC | |
Service Brake/Parking Brake | Hydraulic /Mechanical | |
Hydraulic System Working Pressure | Mpa | 20.0 |
With technological innovation our product configuration and parameters will continue to change without notice;
If there is any doubt the specific confirmation of our international trade sales shall prevail;
