Product Introduction
1. High-Load AC Motor System
Equipped with an industrial-grade high-power AC motor, it supports a load capacity of 7 tons, with strong torque and stable power output. The brushless design reduces maintenance costs, and the motor runs quietly without carbon brush wear, ensuring long-term stable operation even under high-load working conditions.
2. Heavy-Duty Hydraulic System
Equipped with a high-pressure hydraulic system, it can stably lift and transport heavy loads of 7 tons. The hydraulic system has fast response, stable pressure, and strong load-bearing capacity, which can effectively avoid load collapse and ensure safe operation.
3. Intelligent Control System
Equipped with a professional PLC control system, it supports multi-mode adjustment (high/low speed switching). The LCD touch screen displays real-time battery voltage, load capacity, and fault information, enabling quick troubleshooting and reducing downtime.
4. Reinforced Body Structure
Adopts a reinforced frame structure, with thickened steel plates to enhance stability. The widened wheelbase and anti-rollover design ensure safe operation even under full-load (7-ton) conditions, adapting to high-intensity heavy-load handling needs.
5. Application Scenarios
Widely used in large-scale logistics parks, heavy-duty manufacturing plants, port terminals, and high-load industrial scenarios. It is suitable for transporting 7-ton heavy goods, large-scale equipment, and bulk materials, meeting the high-load handling needs of large enterprises and ensuring efficient and environmentally friendly operation.
 |  |  |
Parameters
Model | FB70 | |
Rated Capacity | kg | 7000 |
Load Center Distance | mm | 600 |
Power Type | Lithium Battery | |
Wheel Base | mm | 2250 |
Wheel Number(Front/Rear) | 4×/2 | |
Front Tread | mm | 1470 |
Rear Tread | mm | 1190 |
Tyre(Front) | 8.25-15-14PR | |
Tyre(Rear) | 8.25-15-14PR | |
Front Overhang | mm | 590 |
Mast Tilting Angle,Front/Rear | 6/12 | |
Height With Mast Retraction | mm | 2500 |
Free Lifting Height | mm | 200 |
Max.Lifting Height | mm | 3000 |
Max.Height After Lifting | mm | 4420 |
Overall Guard Height | mm | 2450 |
Fork Size:Length X Width X Thickness | mm | 1220×150×65 |
Overall Length(Fork Excluded) | mm | 3600 |
Overall Width | mm | 1995 |
Turning Radjus | mm | 3180 |
Ground Clearance Of Mast | mm | 200 |
Ground Clearance Of Wheel Base Center(Loaded) | mm | 220 |
Right Angle Stacking Aisle Width (Pallet 1000×1000Mm),Clearance 200Mm | mm | 5195 |
Right Angle Stacking Aisle Width (Pallet 1200×1200Mm),Clearance 200Mm | mm | 5395 |
Lateral Fork Adjustment Max./Min | mm | 1840-300 |
Travelling Speed (Loaded/Unloaded) | km/h | 13/15 |
Lifting Speed (Loaded/Unloaded) | mm/s | 340/380 |
Lowering Speed | mm/s | 430 |
Gradeability (Loaded) | % | 20 |
Self Weight | Kg | 10200 |
Battery Voltage /Capacity | V/Ah | 76.8/608 |
Battery Weight | Kg | 600 |
Driving Motor Power-60 Minutes | Kw | 30 |
Lifting Motor Power(S315%) | Kw | 2X26 |
Driving Motor Control Mode | MOSFET/AC | |
Lifting Motor Control Mode | MOSFET/AC | |
Service Brake/Parking Brake | Hydraulic /Mechanical | |
Hydraulic System Working Pressure | Mpa | 20.0 |
With technological innovation our product configuration and parameters will continue to change without notice;
If there is any doubt the specific confirmation of our international trade sales shall prevail;
