Product Introduction
1. Proven IC Forklift Structure & Stability
Adopts internal combustion (IC) forklift structure, validated by 30+ years of market use. It features exceptional structural strength, reinforced load-bearing components and a balanced chassis, maintaining stability during heavy lifting and reliable performance in demanding industrial environments.
2. Mature & Durable Axle Components
Equipped with mature driving and steering axles from IC forklift technology, with wide market availability, proven durability and easy maintenance. Mechanics are familiar with servicing these components, minimizing downtime and repair complexity.
3. Double Gun Charging Piles for Efficiency
Standard Double Gun charging piles enable efficient charging, extending daily operation time. Compatible with multi-shift workflows, it supports quick charging between uses, ensuring continuous operation and avoiding productivity loss from lengthy charging.
4. Zero-Emission Lithium Iron Phosphate Battery
Powered by high-quality lithium iron phosphate batteries, achieving zero emissions. Suitable for environments with strict environmental requirements (food storage, cleanrooms) and lower noise than IC models, creating a more comfortable workspace.
5. Advanced Compact Motor Drive System
Advanced motor drive system with compact design delivers strong driving and climbing performance, providing sufficient torque for heavy lifting and maneuvering. Responsive controls enable precise movements, balancing power and efficiency for tight spaces.
6. Application Scenarios
Widely used in warehouses, production facilities, food storage, cleanrooms and demanding industrial sites, suitable for heavy material handling, multi-shift operations and environments requiring zero emissions, low noise and high reliability.
 |  |  |  |  |
Parameters
Model | FB50 | |
Rated Capacity | kg | 5000 |
Load Center Distance | mm | 600 |
Power Type | Lithium Battery | |
Wheel Base | mm | 2250 |
Wheel Number(Front/Rear) | 4×/2 | |
Front Tread | mm | 1470 |
Rear Tread | mm | 1700 |
Tyre(Front) | 8.25-15-14PR | |
Tyre(Rear) | 8.25-15-14PR | |
Front Overhang | mm | 590 |
Mast Tilting Angle,Front/Rear | 6/12 | |
Height With Mast Retraction | mm | 2500 |
Free Lifting Height | mm | 200 |
Max.Lifting Height | mm | 3000 |
Max.Height After Lifting | mm | 4420 |
Overall Guard Height | mm | 2450 |
Fork Size:Length X Width X Thickness | mm | 1220×150×55 |
Overall Length(Fork Excluded) | mm | 3440 |
Overall Width | mm | 1995 |
Turning Radjus | mm | 3250 |
Ground Clearance Of Mast | mm | 200 |
Ground Clearance Of Wheel Base Center(Loaded) | mm | 220 |
Right Angle Stacking Aisle Width (Pallet 1000×1000Mm),Clearance 200Mm | mm | 5085 |
Right Angle Stacking Aisle Width (Pallet 1200×1200Mm),Clearance 200Mm | mm | 5285 |
Lateral Fork Adjustment Max./Min | mm | 1840-300 |
Travelling Speed (Loaded/Unloaded) | km/h | 14/16 |
Lifting Speed (Loaded/Unloaded) | mm/s | 360/400 |
Lowering Speed | mm/s | 420 |
Gradeability (Loaded) | % | 25 |
Self Weight | Kg | 9000 |
Battery Voltage /Capacity | V/Ah | 76.8/560 |
Battery Weight | Kg | 540 |
Driving Motor Power-60 Minutes | Kw | 30 |
Lifting Motor Power(S315%) | Kw | 2X26 |
Driving Motor Control Mode | MOSFET/AC | |
Lifting Motor Control Mode | MOSFET/AC | |
Service Brake/Parking Brake | Hydraulic /Mechanical | |
Hydraulic System Working Pressure | Mpa | 20.0 |
With technological innovation our product configuration and parameters will continue to change without notice;
If there is any doubt the specific confirmation of our international trade sales shall prevail;
