China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 4.5t battery forklift | fb45 in China. With abundant experience, we warmly welcome you to buy cheap 4.5t battery forklift | fb45 made in China here from our factory. For price consultation, contact us.
Product Introduction
1. High-Performance AC Brushless Motor
Outperforming DC motors, the AC brushless motor boasts higher max speed, compact yet powerful structure, and quick start-up to reach full speed in short distances, boosting efficiency in busy warehouses and tight production zones. No carbon brush/diverter replacement, cutting maintenance costs and minimizing downtime.
2. Heding High-Quality Lithium Battery
Standard Heding lithium battery with 5-year warranty, featuring zero pollution and maintenance-free operation. 1.5-2h fast charging supports seamless multi-shift work, ideal for 24/7 production lines, logistics centers and cold storage facilities needing continuous performance.
3. Intelligent ZAPI Electronic Control System
ZAPI electronic control enables precise management of starting, driving and loading. It integrates ramp braking (anti-rollback) and fault self-diagnosis to quickly identify issues, enhancing operational safety, efficiency and reliability.
4. Durable Braking & Steering System
Maintenance-free wet disc brake provides consistent stopping power. Cast steering axle with compact design, minimal deflection, dust-proof and water-proof features ensures long-term durability and stable operation.
5. Application Scenarios
Designed for heavy material handling, it's widely used in busy warehouses, tight production zones, logistics centers, cold storage facilities and 24/7 production lines, suitable for demanding industrial environments with high performance and low ownership cost.
 |  |  |  |
 |  |  |  |
 |  |  |  |  |
Parameters
Model | FB45 | |
Rated Capacity | kg | 4500 |
Load Center Distance | mm | 500 |
Power Type | Lithium Battery | |
Wheel Base | mm | 1800 |
Wheel Number(Front/Rear) | 2×/2 | |
Front Tread | mm | 1160 |
Rear Tread | mm | 970 |
Tyre(Front) | 250-15-12PR | |
Tyre(Rear) | 18X7-8-16PR | |
Front Overhang | mm | 520 |
Mast Tilting Angle,Front/Rear | 6/12 | |
Height With Mast Retraction | mm | 2150 |
Free Lifting Height | mm | 150 |
Max.Lifting Height | mm | 3000 |
Max.Height After Lifting | mm | 4272 |
Overall Guard Height | mm | 2092 |
Fork Size:Length X Width X Thickness | mm | 1070×125×50 |
Overall Length(Fork Excluded) | mm | 2690 |
Overall Width | mm | 1420 |
Turning Radjus | mm | 2550 |
Ground Clearance Of Mast | mm | 130 |
Ground Clearance Of Wheel Base Center(Loaded) | mm | 130 |
Right Angle Stacking Aisle Width (Pallet 1000×1000Mm),Clearance 200Mm | mm | 4250 |
Right Angle Stacking Aisle Width (Pallet 1200×1200Mm),Clearance 200Mm | mm | 4450 |
Lateral Fork Adjustment Max./Min | mm | 1300/250 |
Travelling Speed (Loaded/Unloaded) | km/h | 12/13 |
Lifting Speed (Loaded/Unloaded) | mm/s | 250/350 |
Lowering Speed | mm/s | <600 |
Gradeability (Loaded) | % | 14 |
Self Weight | Kg | 5440 |
Battery Voltage /Capacity | V/Ah | 80/460 |
Battery Weight | Kg | 1170 |
Driving Motor Power-60 Minutes | Kw | 16.6 |
Lifting Motor Power(S315%) | Kw | 13.5 |
Driving Motor Control Mode | Full AC | |
Lifting Motor Control Mode | Full AC | |
Service Brake/Parking Brake | Hydraulic /Mechanical | |
Hydraulic System Working Pressure | Mpa | 20.0 |
With technological innovation our product configuration and parameters will continue to change without notice;
If there is any doubt the specific confirmation of our international trade sales shall prevail;
