China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 3t battery forklift | fb30 in China. With abundant experience, we warmly welcome you to buy cheap 3t battery forklift | fb30 made in China here from our factory. For price consultation, contact us.
Product Introduction
Intelligent Safety Features
Equipped with an electric lock + card-start system, the BMS battery management controller enables real-time monitoring and three-level fault protection. The seat automatically powers off when unoccupied, while the handbrake features a locking mechanism with audible alarms, ensuring comprehensive operational safety.
Comfort and Convenience Design
The standard luxury shock-absorbing seat reduces long-hour operation fatigue. The gear-type handbrake offers reliable stability, paired with a wide-vision mast for optimal visibility. The drawer-style battery pack allows easy maintenance and quick replacement, minimizing downtime for repairs.
High Efficiency and Range
Featuring a high-performance lithium iron phosphate battery with fast-charging capability and extended warranty, the motor-driven oil pump enhances operational efficiency. The braking energy recovery system extends driving range while reducing component wear, balancing productivity and durability.
Upgraded Body and Hydraulic System
The newly optimized body structure improves load capacity and range, adapting to diverse working conditions. The split-type hydraulic oil tank design minimizes energy loss and simplifies maintenance, with a large capacity supporting various attachment installations for versatile applications.
The 3-ton electric forklift, combining "high load capacity, low energy consumption, and intelligence", has become a green solution for medium and large material handling. It is particularly suitable for logistics enterprises and manufacturing plants with daily operation hours exceeding 5 hours, which focus on full-cycle cost control.
 |  |  |  |
Parameters
1 | Model | Unit | FB30(Lithium) | |
3 | Rated Capacity | (kg) | 3000 | |
4 | Load Centre | (mm) | 500 | |
5 | Battery(Voltage/Capacity ) | (V/Ah) | 80/272 | |
6 | Max.Lifting Height | (mm) | 3000 | |
7 | Free lift height | (mm) | 130 | |
8 | Mast Tilt Angle(Front/Rear) | (°) | 6°/10° | |
9 | Max.Lifting speed(Full/No load) | (mm/s) | 280/350 | |
10 | Max. Speed(Full/No load) | (km/h) | 14/15 | |
11 | Min. Turning Radius | (mm) | 2285 | |
12 | Gradeability(Full/No load) | (%) | 15/15 | |
13 | Weight (with/without battery) | (kg) | 4390/4170 | |
14 | Tractionn | (N) | 17000 | |
15 | Overall Length (without fork) | (mm) | 2528 | |
16 | Width | (mm) | 1260 | |
17 | Height | Height of Mast | (mm) | 2115 |
Height to head guard | (mm) | 2150 | ||
18 | Max.Lifting Height | (mm) | 4272 | |
19 | Minimum Ground Clearance(mast) | (mm) | 145 | |
20 | Wheelbase | (mm) | 1650 | |
21 | Wheel Tread | Front | (mm) | 1000 |
22 | Rear | (mm) | 960 | |
23 | Front Overhang | (mm) | 485 | |
24 | Tyre | Front | 28×9-15 | |
25 | Rear | 18×7-8 | ||
26 | Forks(L*W*H) | (mm) | 1220×122×45 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
If there is any doubt, the specific confirmation of our international trade sales shall prevail;
