China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 3.5t all wheel drive rough terrian forklift | fdr35-4w in China. With abundant experience, we warmly welcome you to buy cheap 3.5t all wheel drive rough terrian forklift | fdr35-4w made in China here from our factory. For price consultation, contact us.
Key Features
Real-Time LCD Monitoring System
Fully integrated LCD instrument with CAN bus technology enables real-time monitoring of the forklift's operating status.
Heavy-Duty Industrial Tires
Wide-profile tires provide enhanced stability and improved lifting capacity in rough and uneven working environments.
Wide-View Mast Design
Optimized mast structure ensures excellent forward visibility, improving work efficiency and operational safety.
High Ground Clearance
Increased ground clearance enhances maneuverability and ensures smooth operation across challenging terrains.
Optimized Steering Performance
Upward-positioned steering cylinder reduces turning radius and increases rear wheel steering angle for greater flexibility.
High-Mounted Exhaust System
Equipped with a drip-proof exhaust outlet for improved safety and reliability in harsh conditions.
 |  |  |
Parameters
Model | FDR35-4W | ||
Power Type | Diesel | ||
Rated Capacity | Kg | 3500 | |
Load Centre | mm | 500 | |
Lift Height | mm | 3000 | |
Mast Tilt Angle(F/R) | Deg | 8/12 | |
Front Overhang | mm | 590 | |
Wheelbase | mm | 1990 | |
Tread(Front/Rear) | mm | 1300/1205 | |
Lifting Speed(Full Load) | mm/s | 420 | |
Droping Speed(No Load) | mm/s | 550 | |
Travel Speed (No Load) | Km/h | 22 | |
Max. Gradeability(Full Load) | % | 16 | |
Weight | Kg | 5850 | |
Fork Size(L×W×T) | mm | 1070*122*50 | |
Length(Without Fork) | mm | 3260 | |
Width | mm | 1630 | |
Mast Extended Height | mm | / | |
Mast Lowered Height | mm | 2280 | |
Overhead Guard Height | mm | 2250 | |
Min. Turning Radius | mm | 3450 | |
Ground Clearance(Bottom of mast) | mm | 200 | |
Engine | Model | 4D32XG30 | |
Manufacture | XINCHAI | ||
Rated output/r.p.m. | Kw/r | 45/2500 | |
Rated torque/r.p.m. | Nm/r | 200/1500-1800 | |
Displacement | L | 3-3.8 | |
Battery | Voltage | V | 12 |
capacity | Ah | 80 | |
Transmission | Type | Hydraulic | |
Stage(FWD/RVS) | 2/2 | ||
Tire | Type | Pneumatic Tyre | |
Front | 14-17.5NHS | ||
Rear | 10.0/75-15.3IMP | ||
With technological innovation, our product configuration and parameters will continue to change without notice;
If there is any doubt, the specific confirmation of our international trade sales shall prevail;
