China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 3.5t two wheel drive rough terrian forklift | fdr35-2w in China. With abundant experience, we warmly welcome you to buy cheap 3.5t two wheel drive rough terrian forklift | fdr35-2w made in China here from our factory. For price consultation, contact us.
Key Features
Excellent Rough Terrain Performance
Equipped with a limited-slip gearbox and specialized differential structure, combined with wide off-road tires and deep tread patterns, ensuring strong traction on uneven ground.
Advanced Shock Absorption System
Four cushion mounts between the overhead guard and frame create a secondary suspension system, paired with a full suspension seat to effectively reduce vibration and operator fatigue.
Easy Maintenance Access
Key components such as the electrical control box, air filter, and battery are easily accessible, allowing quick inspection and tool-free maintenance.
High-Mounted Exhaust Design
Features a drip-proof exhaust outlet, enhancing safety and durability in harsh working environments.
Ergonomic & Intelligent Operation
Designed for operator comfort, with an LCD display and electronic shifting system for smooth and easy control.
Efficient Air Filtration System
Double air filter design provides strong air purification, ensuring reliable performance in dusty outdoor conditions.
Reinforced Mast Structure
Wider and stronger mast design improves visibility, enhances stability, and ensures safer operation.
 |  |  |
Parameters
Model | FDR35-2W | ||
Power Type | Diesel | ||
Rated Capacity | Kg | 3500 | |
Load Centre | mm | ||
Lift Height | mm | 3000 | |
Mast Tilt Angle(F/R) | Deg | 8/12 | |
Front Overhang | mm | 590 | |
Wheelbase | mm | 1850 | |
Tread(Front/Rear) | mm | 1300/1205 | |
Lifting Speed(Full Load) | mm/s | 420 | |
Droping Speed(Full Load/No Load) | mm/s | 600/300 | |
Travel Speed (Full Load) | Km/h | 22 | |
Max. Gradeability(Full Load) | % | 16 | |
Weight | Kg | 4950 | |
Fork Size(L×W×T) | mm | 1070x122x50 | |
Length(Without Fork) | mm | 3100 | |
Width | mm | 1660 | |
Mast Extended Height | mm | 4350 | |
Mast Lowered Height | mm | 2185 | |
Overhead Guard Height | mm | 2300 | |
Min. Turning Radius | mm | 2930 | |
Ground Clearance(Bottom of mast) | mm | 220 | |
Engine | Model | 498 | |
Manufacture | XINCHAI | ||
Rated output/r.p.m. | Kw/r | 45/2500 | |
Rated torque/r.p.m. | Nm/r | 193/1800 | |
Displacement | L | 3.17 | |
Battery | Voltage | V | 12 |
capacity | Ah | 80 | |
Transmission | Type | Hydraulic | |
Stage(FWD/RVS) | Ⅰ/Ⅰ | ||
Tire | Type | Pneumatic Tyre | |
Front | 14-17.5-16PR | ||
Rear | 10-16.5-12PR | ||
With technological innovation, our product configuration and parameters will continue to change without notice;
If there is any doubt, the specific confirmation of our international trade sales shall prevail;
