China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 3t two wheel drive rough terrian forklift | fdr30-2w in China. With abundant experience, we warmly welcome you to buy cheap 3t two wheel drive rough terrian forklift | fdr30-2w made in China here from our factory. For price consultation, contact us.
Key Features
Outstanding Rough Terrain Capability
Limited-slip gearbox with a specialized differential structure, combined with wide off-road tires and deep tread patterns, ensures excellent performance on uneven ground.
Enhanced Suspension & Operator Comfort
Dual shock absorption system with four cushion supports and a full suspension seat effectively reduces vibration and operator fatigue.
Tool-Free Maintenance Access
Easy access to key components such as the electrical control box, air filter, and battery, allowing quick maintenance without tools.
High-Mounted Exhaust System
Equipped with a drip-proof exhaust outlet, improving durability and safety in demanding environments.
Ergonomic & User-Friendly Operation
Features an LCD display, electronic shifting, and intuitive controls for smooth and comfortable operation.
Efficient Air Filtration System
Double air filter design provides strong air purification, ideal for dusty outdoor conditions.
Reinforced Mast Structure
Wider and stronger mast design offers improved visibility, enhanced stability, and higher safety during operation.
 |  |  |
Parameters
Model | FDR30-2W | ||
Power Type | Diesel | ||
Rated Capacity | Kg | 3000 | |
Load Centre | mm | 500 | |
Lift Height | mm | 3000 | |
Mast Tilt Angle(F/R) | Deg | 8/12 | |
Front Overhang | mm | 545 | |
Wheelbase | mm | 1850 | |
Tread(Front/Rear) | mm | 1250/1205 | |
Lifting Speed(Full Load) | mm/s | 440 | |
Droping Speed(Full Load/No Load) | mm/s | 600/300 | |
Travel Speed (Full Load) | Km/h | 22 | |
Max. Gradeability(Full Load) | % | 16 | |
Weight | Kg | 4800 | |
Fork Size(L×W×T) | mm | 1070x122x45 | |
Length(Without Fork) | mm | 3050 | |
Width | mm | 1550 | |
Mast Extended Height | mm | 4350 | |
Mast Lowered Height | mm | 2185 | |
Overhead Guard Height | mm | 2210 | |
Min. Turning Radius | mm | 2910 | |
Ground Clearance(Bottom of mast) | mm | 220 | |
Engine | Model | 495 | |
Manufacture | XINCHAI | ||
Rated output/r.p.m. | Kw/r | 42/2650 | |
Rated torque/r.p.m. | Nm/r | 174/1800-2000 | |
Displacement | L | 2.98 | |
Battery | Voltage | V | 12 |
capacity | Ah | 80 | |
Transmission | Type | Hydraulic | |
Stage(FWD/RVS) | Ⅰ/Ⅰ | ||
Tire | Type | Pneumatic Tyre | |
Front | 12-16.5-14PR | ||
Rear | 27x10.5-15PR | ||
With technological innovation, our product configuration and parameters will continue to change without notice;
If there is any doubt, the specific confirmation of our international trade sales shall prevail;
