China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 2.5t two wheel drive rough terrian forklift | fdr25-2w in China. With abundant experience, we warmly welcome you to buy cheap 2.5t two wheel drive rough terrian forklift | fdr25-2w made in China here from our factory. For price consultation, contact us.
Key Features
Superior Off-Road Performance
Equipped with a limited-slip gearbox, reinforced differential, and wide deep-tread tires for excellent traction on rough terrain.
Advanced Shock Absorption System
Dual-stage suspension with cushion mounts and a full suspension seat significantly reduces vibration and operator fatigue.
Easy Maintenance Access
Key components such as the electrical control box, air filter, and battery are easily accessible without tools, ensuring quick servicing.
High-Mounted Exhaust System
Designed with a drip-prevention structure, improving safety and reliability in harsh working environments.
Ergonomic & Smart Operation
Features an LCD display, electronic shifting system, and user-friendly controls for comfortable and efficient operation.
Enhanced Air Filtration
Double air filter system provides strong air purification, ideal for dusty and demanding outdoor conditions.
Reinforced Mast Design
Wider and stronger mast structure ensures better visibility, higher stability, and improved operational safety.
 |  |  |
Main Applications
Construction sites with uneven or muddy terrain
Mining and quarry operations
Forestry and agricultural material handling
Logistics handling in outdoor yards and ports
Infrastructure and road construction projects
Parameters
2.5 Ton Rough Terrain Forklift parameter | |||
Model | FDR25-2W | ||
Power Type | Diesel | ||
Rated Capacity | Kg | 2500 | |
Load Centre | mm | 500 | |
Lift Height | mm | 3000 | |
Mast Tilt Angle(F/R) | Deg | 8/12 | |
Front Overhang | mm | 545 | |
Wheelbase | mm | 1850 | |
Tread(Front/Rear) | mm | 1250/1205 | |
Service Brake | hydraulic | ||
Parking Brake | clutch | ||
Lifting Speed(Full Load) | mm/s | 450 | |
Droping Speed(Full Load/No Load) | mm/s | 600/300 | |
Travel Speed (Full Load) | Km/h | 22 | |
Max. Gradeability(Full Load) | % | 17 | |
Weight | Kg | 4650 | |
Fork Size(L×W×T) | mm | 1070x122x45 | |
Length(Without Fork) | mm | 3050 | |
Width | mm | 1550 | |
Mast Extended Height | mm | 4350 | |
Mast Lowered Height | mm | 2185 | |
Overhead Guard Height | mm | 2210 | |
Min. Turning Radius | mm | 2910 | |
Ground Clearance(Bottom of mast) | mm | 220 | |
Engine | Model | 495 | |
Manufacture | XINCHAI | ||
Rated output/r.p.m. | Kw/r | 42/2650 | |
Rated torque/r.p.m. | Nm/r | 174/1800-2000 | |
Displacement | L | 2.98 | |
Battery | Voltage | V | 12 |
capacity | Ah | 80 | |
Transmission | Type | Hydraulic | |
Stage(FWD/RVS) | Ⅰ/Ⅰ | ||
Tire | Type | Pneumatic Tyre | |
Front | 12-16.5-14PR | ||
Rear | 27x10.5-15PR | ||
With technological innovation, our product configuration and parameters will continue to change without notice;
If there is any doubt, the specific confirmation of our international trade sales shall prevail;
