China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 45t reach stacker | c45v in China. With abundant experience, we warmly welcome you to buy cheap 45t reach stacker | c45v made in China here from our factory. For price consultation, contact us.
Fuel and Maintenance Savings
■ 15% lower fuel use
■ Long-life filters reduce costs
Smooth Control
■ Multi-valve spreader system
■ Fast response <300ms
Proven Durability
■Structure tested for 30,000 hours fatigue life
Product Parameters
 |  |  |  |
Technical Parameter | Configuration Parameter | ||||
ITEM | UNIT | SRSC45V series | CONFIGURATION | UNIT | SRSC45V series |
Max. Lifting Speed (0/full load) | mm/s | 420/250 | Type | - | TAD191VE |
Max. Lowering Speed (0/full load) | mm/s | 360/300 | Rated Capacity | kW/rpm | 265/2100 |
Max. Traveling Speed (0/full load) | km/h | 25/21 | Max Torque | Nm/rpm | 1780/1400 |
Gradeability (0/full load) | % | 39/32 | Emission Standard | - | StageⅢ |
Hydraulic System Working Pressure | bar | 260 | Type | - | X12 |
Rated Capacity | kW/rpm | 277/2100 | |||
Overall Weight | t | 71 | Max Torque | Nm/rpm | 1850/200~1600 |
Rated Load | t | 45 | Emission Standard | - | StageⅢ |
Stack Layer | - | 5 | Type | - | Cummins QSL9T4F |
Max. Lift Height Standard | mm | 15100 | Rated capacity | kW/rpm | 272/2100 |
Max. Boom Elevation | deg | 0~60 | MaxTorque | N·m/rpm | 1795/1400 |
Overall Length (L) | mm | 11320 | Emission Standard | - | Tier 4F |
Wheel Base (L1) | mm | 6000 | Type | - | TAD191VE |
Overall Height(H) (retract/extend) | mm | 4770 | Rated Capacity | kW/rpm | 265/2100 |
Max Torque | N·m/rpm | 1795/1400 | |||
Min. Ground Clearance (H1) | mm | 300~350 | Emission Standard | - | Stage V |
Overall Width (W) | mm | 6055-12185 | Transmission Type | - | 15,SHR36432-35 |
Counterweight Sideways (E) | mm | - | Drive Axle Type | - | 15,7TE30510-7 |
Main Valve | - | Kessler D102 | |||
Front Gauge (T1) | mm | 3033 | Main Pump | - | XWF-S10 |
Rear Gauge (T2) | mm | 2790 | Model | - | Parker |
Min. Turning Radius | mm | 8000 | Lateral Move | mm | +800 |
Aisle Width For 20'container | mm | 11300 | Rotate Angle | deg | 105°~195° |
Aisle Width For 40'container | mm | 13600 | Tilt Angle | deg | ±5 |
Self-Weight | t | 71 | |||
Suitable Fo | - | ISO20/40/45/Container | |||
Tires | - | 18.00-25 | |||
