China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 160hp swamp bulldozer | hd16s in China. With abundant experience, we warmly welcome you to buy cheap 160hp swamp bulldozer | hd16s made in China here from our factory. For price consultation, contact us.
Key Features
Ultra-Low Ground Pressure Tracks
Triangular wide tracks reduce ground pressure, preventing sinking in soft soil, marshes, and wetlands.
High-Power Engine
Weichai WD10G178E25 provides reliable torque and fuel efficiency for challenging wetland operations.
Enhanced Hydraulic & Cooling System
14MPa hydraulic system with overload protection and advanced cooling ensures smooth operation in extreme conditions.
Stable Frame & Flexible Operation
Full box-type welded frame with swing-type suspension maintains stability on soft or uneven terrain.
 |  |
Main Applications
Wetland and marshland construction
Water conservancy and dredging projects
Soft soil and swamp area operations
Land reclamation and environmental engineering
Main specification
Model | HD16S |
Type | 160HP Hydraulic Swamp Crawler Type |
| Engine model | Weichai WD10G178E25 |
Displacement(L) | 9.726 |
Rated power(kw/rpm) | 131/1850 |
Max.torque(N.m/rpm) | 830/1000-1200 |
Operating weight | 18.1 Ton |
Dimension(no ripper)(mm) | 5176×4190×3170 |
Grounding Length(mm) | 2935 |
Ground pressure(MPa) | 0.032 |
Track gauge(mm) | 2300 |
Dozing capacity(m³) | 3.8 |
Blade width(mm) | 4190 |
Blade height(mm) | 962 |
Digging depth(mm) | 485 |
Blade lifting height(mm) | 1005 |
Track shoe width(mm) | 950(optional 1100) |
Pitch(mm) | 203.2 |
Quantity of track link | 42 |
Quantity of Carrier rollers(each side) | 2 |
Quantity of Track rollers(each side) | 7 |
Forward Speed(Km/h) | F1:0-3.29 |
F2:0-5.82 | |
F3:0-9.63 | |
Rear Speed(Km/h) | R1:0-4.28 |
R2:0-7.59 | |
R3:0-12.53 |
