China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 3t hydraulic drive road roller | ltc203 in China. With abundant experience, we warmly welcome you to buy cheap 3t hydraulic drive road roller | ltc203 made in China here from our factory. For price consultation, contact us.
Product Introduction
Compact & Versatile:
Small, integral design ideal for narrow roads, groove foundations, pipeline backfill, stadiums, and building construction
Hydraulic Double-Wheel Drive:
Front and rear wheels vibrate and steer hydraulically, ensuring reliable performance and cost-effectiveness
Scraper & Water Spray:
Both front and rear drums equipped with scraping and water spray units for efficient compaction and dust control
Powerful Diesel Engine:
Equipped with ZN390B 26.5 kW diesel engine; easy to operate and maintain
Strong Compaction:
Centrifugal force 2×30 kN, vibration amplitude 0.5 mm, vibration frequency 50 Hz
Good Mobility:
Max travel speed 0–12 km/h, gradeability 30%, ground clearance 320 mm
Optimal Dimensions:
Drum diameter 700 mm, drum width 1250 mm, wheelbase 2010 mm; compact overall size 2760×1400×2520 mm
Water Supply:
165 L tank for drum spray
Shipping:
2 units per 20GP / 4 units per 40HQ
 |  |  |
 |  |  |
Model | LTC203 |
Operating mass | 3000kg |
Static linear load | Front 130/ Rear 130N/cm |
Vibration amplitude | Front 0.5/ Rear 0.5mm |
Centrifugal force | 2x30Kn |
Vibration frequency | 50Hz |
Max Travel speed | 0-12Km/h |
Ground clearance | 320mm |
Electrical voltage | 24V |
Grade ability | 30% |
Overall dimension (LxWxH) | 2760x1400x2520mm |
Drum diameter | 700mm |
Drum width | 1250mm |
Wheel base | 2010mm |
Diesel engine power | 26.5Kw |
Diesel engine model | ZN390B |
Water tank capacity | 165L |
Ship | 2units/20GP 4units/40HQ |
