China Machinery International Trading Co., Ltd. is one of the leading manufacturers and suppliers of 16t motor grader | py180c in China. With abundant experience, we warmly welcome you to buy cheap 16t motor grader | py180c made in China here from our factory. For price consultation, contact us.
Description
The PY180C motor grader is a high-efficiency, multi-functional construction machine for land leveling, grading, ditching, ripping, scarifying, bulldozing, and snow removal. Perfect for highways, railways, airports, ports, dams, industrial sites, and farmland, it combines power, precision, and versatility for modern infrastructure projects.
 |  |
Key Features
Powerful Engine:
Turbocharged CUMMINS diesel, water-cooled for reliable and efficient performance.
Smooth Transmission:
Integrated ZF torque converter & power-shift gearbox (6F/3R) for heavy loads and transport.
Stable Steering & Drive:
Center-articulated joint, tilting front wheels, oscillated front axle, anti-slip differential for precise maneuvering.
Advanced Blade Control:
Pendulum-arm blade, dual tip adjustment, HUSCO hydraulic valves, and patented hydraulic pin system for accurate grading.
Operator Comfort & Safety:
Spacious cab, electro-hydraulic monitoring, OPTIMA maintenance-free batteries, caliper disc brakes, and parking brake.
Optional Attachments:
Front bulldozing blade and rear ripper for enhanced versatility.
SEO Keywords:
PY180C motor grader, articulated grader, self-propelled grader, highway construction equipment, CUMMINS diesel grader, hydraulic blade control, multi-functional grader
 |  |
Model | PY180C |
Operating mass | 16000kg |
Max. forward speed | 36 Km/h |
Max. backward speed | 25Km/h |
Front axle load | 5150kg |
Rear axle load | 10850kg |
Speed gear number | F6/R3 |
Minimum Turning radius | 7800mm |
Hydraulic system pressure | 18Mpa |
Blade length × height | 3965×610 mm |
Blade tilt angle | ±90° |
Blade slewing angle | 360° |
Front wheel tilt angle | ±17° |
Front wheel track | 2150 mm |
Rear wheel track | 2255mm |
Overall dimension (LxWxH) | 8605×2695× 3420mm |
Wheel base | 5647mm |
Diesel engine power | 132kw/2200rpm |
Diesel engine model | CUMMINS 6BTA5.9 |
Fuel tank capacity | 228L |
Hydraulic tank capacity | 170L |
Tire seize | 17.5-25 |
Multi tandem Valve | Husco |
Rear Ripper | 5 teeth |
Optional: Front bulldozer blade +Rear ripper | |
